Nortel Norstar 7310 Meridian Business Telephone SystemsOur local certified technicians and our access to repair and replacement parts will keep your system operational. We service all Nortel telephone systems including the BCM50, BCM100, BCM200, BCM400, BCM450, CICS and MICS running conventional telephony using the M7310 M7324 M7208 M7100 model telephones and the IP based telephones. Nortel phones have been a leader in communication services for decades, and Ohio Tele-Net is proud to offer Nortel’s high quality and reliable business phones and systems to its customers.Nortel Norstar 7310 Meridian Business Telephone Systems
To Log Into System Programming:
1. Press FEATURE * * 2 6 6 3 4 4
2. Enter Password: 2 6 6 3 4 4       Display will read: ” A. Configuration”
Programming System Speed Dials:
Follow steps 1-3 under “Log Into System Features”
4. Press: SHOW    Display will read: “1. Sys speed dial”
5. Press: SHOW     Display will read: “Speed Dial #:___”
6. Enter: 01 or 02 or 03 etc…      Display will read: “Speed dial #:01”Nortel Norstar 7310 Meridian Business Telephone Systems
7. Press: SHOW     Display will read: “No number stored”
8. Press the “CHANGE” softkey.     Display will read: “#01:
9. Enter the Speed Dial number
10. Press the “OK” softkey.
11. Press: NEXT     Display will read: “Use prime line”
12. Press: NEXT     Display will read: “Display digits:Y”Nortel Norstar 7310 Meridian Business Telephone Systems
13. Press: NEXT     Display will read: “Bypass restr’n:N”
14. Press: NEXT     Speed dial 01 has now been programmed:
To program another Speed Dial Number, repeat steps 6 thru 14.

Changing a name on a phone
Follow steps 1-3 under “Log Into System Features”
4. Press: SHOW     Display will read: “1. Sys speed dial”
5. Press: NEXT      Display will read: “2. Names”
6. Press the SHOW     Display will read: “Set names”Nortel Norstar 7310 Meridian Business Telephone Systems
7. Press: SHOW     Display will read: “Show set:__”
8. Enter the extension number of which you wish to change the name
9. Press the CHANGE softkey
10. Using the dial pad spell out the name
11. Press: NEXT (if you fail to do this step, the name will not be saved!!!)
12. Press the RLS key
Nortel Norstar 7310 Meridian Business Telephone Systems
To Change the Time and date:
1. Press FEATURE * * T I M E
2. Enter Password: 2 6 6 3 4 4
3. Press NEXT      Display will read: “Date DD MM YY”
4. Press the CHANGE softkey     Display will read: “Year: # # “
5. Press the CHANGE softkey, (If the year is incorrect)     Display will read: “Year: _ “
6. Enter the new YEAR        Display will then read the new Year programmed.
7. Press NEXT       Display will read: “Month: # # “Nortel Norstar 7310 Meridian Business Telephone Systems
8. Press the CHANGE softkey, (If the month is incorrect)      Display will read: “Month: _ “
9. Enter the new MONTH      Display will then read the new Month programmed
10. Press NEXT     Display will read: “Month: # # “
11 Press the CHANGE softkey, (If the day is incorrect)     Display will read: “Day: _ “
12. Enter the new DAY     Display will then read the new Day programmed
13. Press the CHANGE softkey     Display will read: “Hour:
14. Press the CHANGE softkey         Display will read: “Hour: _ “
15. Enter the new HOUR. (in 24-hour format – Ex.: 5:00pm = 17:00.
Display will then read the new Hour programmed.
16. Press NEXT     Display will read: “Minutes: # # “
17. Press the CHANGE softkey       Display will read: “Minutes”: _ “
18. Enter the new MINUTES.Nortel Norstar 7310 Meridian Business Telephone Systems

Nortel is known throughout the world as a leader in communication services, including Voice over IP. With a business phone system from Nortel, your company will be able to take advantage of Nortel’s years of experience as an innovator in the communication technology field.An effective and reliable communication system is vital to the success of your business. Without a reliable phone system, you may be prone to missing or dropping calls from customers, which could lead to a dramatic loss in revenue. Also, an ineffective communication system with fellow employees can lead to decreased productivity and efficiency. In either case, an unreliable phone system could dramatically affect your bottom line. By using Nortel phones, you will be able to avoid all of these problems. Trying to fix a faulty phone system can take up much of your valuable time – time which you should be spending doing the work you are supposed to be doing. With Nortel phones, customer service and employee efficiency will be maximized. To find the Nortel phone system that will best suit your business, browse through our inventory of Nortel Phones.Nortel M7208 Telephone (model NT8B30)Nortel M7310 Telephone (model NT8B20)Nortel M7324 Telephone (model NT8B40)Nortel Networks T7208 Telephone (model NT8B26)Nortel Networks T7316 Telephone (model NT8B27A)Nortel Networks T7316E Telephone (model NT8B27JA)

Nortel Norstar 7310 Meridian Business Telephone Systems

Legacy Business Telephone Systems:
Do you have a legacy telephone system and are looking for a new vendor? We are ready to serve!!! Our seasoned Technicians work on Vertical, Comdial, Nortel, Vodavi, Toshiba, AT&T, Avaya, Lucent, Panasonic, NEC and many others.

Nortel Norstar 7310 Meridian Business Telephone Systems

Call now to schedule your appointment!!!
800-821-2686

Nortel Norstar 7310 Meridian Business Telephone Systems

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

https://cincinnatiohiotele.com/manuals/Nortel%20Norstar%20Meridian/BCM%20M7324N%20User%20Card%20-%20Version%202.pdf

Nortel Norstar 7310 Meridian Business Telephone Systems
Shift button
For using the top function of a dual-memory button.
Display button
Show line:_
COPY
Display message
Display button message OK
Page 2 Enterprise Edge M7310 User Card
Making and answering calls
Answering calls Answering calls using the handset
When your telephone rings, or º flashes beside an Intercom or line button: Nortel Norstar 7310 Meridian
1. Lift the handset.
OR Nortel Norstar 7310 Meridian
Press the button beside the flashing º before lifting the handset.
Answering calls using Handsfree
When your telephone rings, or º flashes beside an Intercom or line button:
1. Press ©.
Making calls Depending upon the dialing mode programmed on your telephone, you may
¬
have to lift the handset before making a call.
External calls using numbered line buttons
1. If you do not have an external Prime line, press a line button.

2. Dial your call.
External calls using Intercom buttons
1. Lift the handset.
2. If º appears beside an Intercom button, enter a line pool access code. Nortel Norstar 7310 Meridian
OR
Press an Intercom button without º, then enter a line pool access code.
3. When you hear external dial tone, dial your call.
Internal calls using Intercom buttons
1. If you do not have an internal Prime line, press ∆.
2. Dial your call.
Note: Line pool access codes and extension numbers are supplied by
your System Administrator.
Making calls using Handsfree
˙
1. Press © instead of lifting the handset.
Holding Calls
1. Press ˙. The º flashes beside the line on hold.
2. Press the line button with the flashing º to return to the call.
Automatic hold
Calls are put on hold automatically when you switch from one line to another.
Exclusive hold
Use Exclusive Hold (ƒ˙) to keep a call on hold so that it
©
can be retrieved only at your telephone.
System Administrator can program Handsfree for your telephone.
Switching between Handsfree and handset
1. Press © and replace the handset to switch to Handsfree.
2. Pick up the handset to switch back.
Using Mute
1. Press ©microphone OFF.
2. Press © again to turn the microphone ON.
Page 3 Enterprise Edge M7310 User Card
Remember: Press ƒ•‚ to check a memory or line button.
Notice These telephones now conform to the latest standards in relation to the
positioning of Q and Z on the number keys. The Q appears on key number 7
and the Z appears on key number 9.
Programming
memory buttons
External Autodial
1. If you are on a call or an open line
with dial tone, press
˙ or ®
2. Pressƒ•⁄.
3. Press a memory button.
4. Dial the external number.
5. Press OK to store the number.
6. Label your new button.
Internal Autodial
1. If you are on a call or an open line with
dial tone, press
˙ or ® . Nortel Norstar 7310 Meridian
2. Pressƒ•¤.
3. Press a memory button.
4. Dial the station number.
5. Label your new button.
Features
1. If you are on a call or an open line
˙
with dial tone, press
or ®.
2. Pressƒ•‹.
3. Press a memory button.
4. Pressƒ and the
feature code.
5. Label your new button.
Erasing memory buttons
1. If you are on a call or an open line with
dial tone, press
˙ or ®. Nortel Norstar 7310 Meridian
2. Pressƒ•⁄.
3. Press the memory button you want to
erase.
4. Press OK to erase the button.
About memory buttons
Programming memory buttons
Memory buttons store telephone
numbers or feature codes to give
you one-touch dialling or
feature activation.
To use the top function, press
the shift button, then press the
dual-memory button.
There are two types of memory
buttons: single-memory and
dual-memory.
Dual-memory buttons:
To use the bottom function,
press the dual-memory button.
Single-memory buttons:
Single-memory buttons are the
buttons with indicators other
than line or Handsfree buttons.
Page 4 Enterprise Edge M7310 User Card
Setting up the telephone
Connecting the cords ATTENTION Before attempting to
carry out any work on the telephone,
ensure that the line cord is unplugged
from the wall socket.
To remove any of the cords, squeeze
the release latch on the plug and gently
pull the plug from the socket.
Connect the handset cord to the jack
labelled with the telephone icon and
route the cord as shown.
If you are using a headset, route the
cord along the channel in the base and
connect the cord to the telephone jack
that is marked with the headset icon.
Route the line cord through the stand
and connect the cord to the telephone
jack that is marked with the jack icon.
Attach the stand using either pair of
slots; to raise the back of the telephone
to its highest position, use these slots.
Once the above work is complete, plug
the line cord back into its wall socket.
Connect to jack Nortel Norstar 7310 Meridian
from distribution block
Connect to receiver
Page 5 Enterprise Edge M7310 User Card P0908513 Issue 01
